Portable Gas Detectors

SC-8000

Riken Keiki Single Super-Toxic Gas Monitor with internal pump

The SC-8000 is a single toxic gas detector built for tough as well as demanding environments. It is durable and sets new standards for rugged, reliable as well as portable toxic gas detection. The monitor is robust, yet lightweight. It is a sample drawing monitor that is designed to be intrinsically safe. The SC-8000 provides continuous exposure monitoring in safe or hazardous areas.
Riken Keiki SC-8000 Single Toxic Gas Sample Drawing Portable Diagram

Product Features

It sets a new standard for rugged, reliable, portable toxic gas detection. It is robust and lightweight. The SC-8000 is sample drawing and is designed to provide continuous exposure monitoring in safe as well as hazardous areas. It has ATEX Approval.

Users benefit from a large LCD display that makes reading the SC-8000 easy. It is simple to use even when the operator is wearing a hazmat suit. The Unit has data-logging as standard.

For loud environments the unit is equipped with a 95dB alarm that alternates between a high & low pitch so the alarm can be heard in noisy places. This, in addition to three bright LED lamps make the SC-8000 alarms very noticeable.

The unit is intrinsically safe for hazardous areas and designed to be waterproof to IP67. In the SC-8000, users have an extremely rugged unit for the most demanding situations.

SC-8000 can detect some of the most common toxic gases. The SC-8000 detects Silane (SiH4), Phosphine (PH3), Arsine (AsH3), Ammonia (NH3), Hydrogen Chloride (HCl), Chlorine (Cl2) as well as Hydrogen Fluoride (HF), plus many others. See Gas list for all gases.

Applications

Specification

Measuring gas Refer to Gas List
Detection principle Electrochemical
Measuring range Refer to Gas List in Data sheet
Alarm Gas alarm (latched), Flow failure, Sensor disconnection, Low battery, Circuit failure, Calibration failure
Alarm method Lamp, Buzzer
Buzzer sound Over 95dB/30cm
Flow rate 0.5L/min
Power source Dry cell/Li-ion rechargeable battery
Continuous operation Dry cell : Over 18hours / Li-ion rechargeable battery : Over 25hours
Temp./Humid. -10 to 40°C / 20 to 88%RH
Size/weight 164x81x154mm / Approx.1.0kg
Ingress proof rating IP67 equivalent
Explosion proof Exia IIC T4
Approvals ATEX / IECEx, TIIS, CE marking
Functions LCD display (7segments, bar meter), ZERO/SPAN adjustment, Pilot indicator, Pump stop function, Datalogger, Password function, Bump test function
